Ford 347 - 3.400 Stroke

Cylinder Bore Size Show all Cylinder Bore Size
With Rings \ Without Rings Show all With Rings \ Without Rings
Crankshaft Stroke Show all Crankshaft Stroke
Connecting Rod Length Show all Connecting Rod Length
Piston Pin Diameter Show all Piston Pin Diameter
Compression Height Show all Compression Height
Cylinder Head Type Show all Cylinder Head Type
Piston Series Show all Piston Series
TDC Assembly Height Show all TDC Assembly Height
Piston Top Aprox. Comp. Ratio Show all Piston Top Aprox. Comp. Ratio
1-3100-4000 347 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.000 bore 1-3100-4000 347 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.000 bore
$669.95
$669.95
347 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -4cc Flat Top inline Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-10.97, 61cc-10.57, 64cc-10.19
1-3100-4030 347 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.030 bore 1-3100-4030 347 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.030 bore
$669.95
$669.95
347 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -4cc Flat Top inline Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.10, 61cc-10.69, 64cc-10.31
1-3100-4040 347 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.040 bore 1-3100-4040 347 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.040 bore
$669.95
$669.95
347 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -4cc Flat Top inline Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.15, 61cc-10.74, 64cc-10.36
1-3100-4060 347 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.060 bore 1-3100-4060 347 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.060 bore
$669.95
$669.95
347 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -4cc Flat Top inline Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.23, 61cc-10.81, 64cc-10.43
1-3100-4125 363 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.125 bore 1-3100-4125 363 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.125 bore
$669.95
$669.95
363 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -4cc Flat Top inline Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.54, 61cc-11.11, 64cc-10.71
1-3100-4155 363 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.155 bore 1-3100-4155 363 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.155 bore
$669.95
$669.95
363 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -4cc Flat Top inline Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.66, 61cc-11.23, 64cc-10.83
1-3100-4165 363 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.165 bore 1-3100-4165 363 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.165 bore
$669.95
$669.95
363 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -4cc Flat Top inline Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.71, 61cc-11.28, 64cc-10.88
1-3100-4185 363 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.185 bore 1-3100-4185 363 Stroker Small Block Ford 289 - 302 1-FX Series -4cc Flat Top inline Forged Piston Set. 4.185 bore
$669.95
$669.95
363 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -4cc Flat Top inline Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.79, 61cc-11.35, 64cc-10.95
1-3101-4000 347 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.000 bore 1-3101-4000 347 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.000 bore
$719.95
$719.95
347 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -5cc Flat Top Inline/ Twisted Wedge Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-10.83, 61cc-10.44, 64cc-10.07
1-3101-4030 347 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.030 bore 1-3101-4030 347 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.030 bore
$719.95
$719.95
347 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -5cc Flat Top Inline/ Twisted Wedge Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-10.96, 61cc-10.56, 64cc-10.19
1-3101-4040 347 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.040 bore 1-3101-4040 347 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.040 bore
$719.95
$719.95
347 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -5cc Flat Top Inline/ Twisted Wedge Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.01, 61cc-10.61, 64cc-10.24
1-3101-4060 347 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.060 bore 1-3101-4060 347 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.060 bore
$719.95
$719.95
347 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -5cc Flat Top Inline/ Twisted Wedge Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.09, 61cc-10.68, 64cc-10.31
1-3101-4125 363 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.125 bore 1-3101-4125 363 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.125 bore
$719.95
$719.95
363 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -5cc Flat Top Inline/ Twisted Wedge Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.39, 61cc-10.97, 64cc-10.59
1-3101-4155 363 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.155 bore 1-3101-4155 363 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.155 bore
$719.95
$719.95
363 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -5cc Flat Top Inline/ Twisted Wedge Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.52, 61cc-11.09, 64cc-10.71
1-3101-4165 363 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.165 bore 1-3101-4165 363 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.165 bore
$719.95
$719.95
363 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -5cc Flat Top Inline/ Twisted Wedge Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.57, 61cc-11.14, 64cc-10.75
1-3101-4185 363 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.185 bore 1-3101-4185 363 Stroker Small Block Ford 289 - 302 1-FX Series -5cc Flat Top Inline/ Twisted Wedge Forged Piston Set. 4.185 bore
$719.95
$719.95
363 Stroker Small Block Ford 289 - 302 1-FX Series 4032 Alloy Comp Hgt: 1.090" -5cc Flat Top Inline/ Twisted Wedge Pin: .912 Ring Grooves: 1.2/1.2/3MM Stroke: 3.400" Rod: 5.400" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.64, 61cc-11.21, 64cc-10.82
