Pontiac GTO

Pontiac Late

REQUIRED FIELD: Choose Cyl Bore Size First Show all REQUIRED FIELD: Choose Cyl Bore Size First
Piston Top Aprox. Comp. Ratio Show all Piston Top Aprox. Comp. Ratio
Crankshaft Stroke Show all Crankshaft Stroke
Piston Pin Diameter Show all Piston Pin Diameter
Connecting Rod Length Show all Connecting Rod Length
Compression Height Show all Compression Height
Ring Groove Width Show all Ring Groove Width
6157-4190 455 - 4.500 Stroke Pontiac Late FX Series -24cc Dish Top Pontiac Late Forged Piston Set 4.190 inch bore COMP HEIGHT: 1.16 6157-4190 455 - 4.500 Stroke Pontiac Late FX Series -24cc Dish Top Pontiac Late Forged Piston Set 4.190 inch bore COMP HEIGHT: 1.16
from $669.95
from $669.95
496 Pontiac Late , FX, Comp Height: 1.16, -24cc Dish Top, PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.500", ROD: 6.8, Approx Comp Ratio: 62cc-11.69, 87cc-9.47, 124cc-7.47
Choose Options
6157-4190 400 - 4.500 Stroke Pontiac Late FX Series -24cc Dish Top Pontiac Late Forged Piston Set 4.190 inch bore COMP HEIGHT: 1.16 6157-4190 400 - 4.500 Stroke Pontiac Late FX Series -24cc Dish Top Pontiac Late Forged Piston Set 4.190 inch bore COMP HEIGHT: 1.16
from $669.95
from $669.95
496 Pontiac Late , FX, Comp Height: 1.16, -24cc Dish Top, PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.500", ROD: 6.8, Approx Comp Ratio: 62cc-11.69, 87cc-9.47, 124cc-7.47
Choose Options
6157-4180 455 - 4.500 Stroke Pontiac Late FX Series -24cc Dish Top Pontiac Late Forged Piston Set 4.180 inch bore COMP HEIGHT: 1.16 6157-4180 455 - 4.500 Stroke Pontiac Late FX Series -24cc Dish Top Pontiac Late Forged Piston Set 4.180 inch bore COMP HEIGHT: 1.16
from $669.95
from $669.95
494 Pontiac Late , FX, Comp Height: 1.16, -24cc Dish Top, PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.500", ROD: 6.8, Approx Comp Ratio: 62cc-11.65, 87cc-9.44, 124cc-7.45
Choose Options
6157-4180 400 - 4.500 Stroke Pontiac Late FX Series -24cc Dish Top Pontiac Late Forged Piston Set 4.180 inch bore COMP HEIGHT: 1.16 6157-4180 400 - 4.500 Stroke Pontiac Late FX Series -24cc Dish Top Pontiac Late Forged Piston Set 4.180 inch bore COMP HEIGHT: 1.16
from $669.95
from $669.95
494 Pontiac Late , FX, Comp Height: 1.16, -24cc Dish Top, PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.500", ROD: 6.8, Approx Comp Ratio: 62cc-11.65, 87cc-9.44, 124cc-7.45
Choose Options
6157-4150 455 - 4.500 Stroke Pontiac Late FX Series -24cc Dish Top Pontiac Late Forged Piston Set 4.150 inch bore COMP HEIGHT: 1.16 6157-4150 455 - 4.500 Stroke Pontiac Late FX Series -24cc Dish Top Pontiac Late Forged Piston Set 4.150 inch bore COMP HEIGHT: 1.16
from $669.95
from $669.95
487 Pontiac Late , FX, Comp Height: 1.16, -24cc Dish Top, PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.500", ROD: 6.8, Approx Comp Ratio: 62cc-11.51, 87cc-9.33, 124cc-7.36
Choose Options
6157-4150 400 - 4.500 Stroke Pontiac Late FX Series -24cc Dish Top Pontiac Late Forged Piston Set 4.150 inch bore COMP HEIGHT: 1.16 6157-4150 400 - 4.500 Stroke Pontiac Late FX Series -24cc Dish Top Pontiac Late Forged Piston Set 4.150 inch bore COMP HEIGHT: 1.16
from $669.95
from $669.95
487 Pontiac Late , FX, Comp Height: 1.16, -24cc Dish Top, PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.500", ROD: 6.8, Approx Comp Ratio: 62cc-11.51, 87cc-9.33, 124cc-7.36
Choose Options
6150-4190 455 - 4.500 Stroke Pontiac Late FX Series -7cc Flat Top Pontiac Late Forged Piston Set 4.190 inch bore COMP HEIGHT: 1.16 6150-4190 455 - 4.500 Stroke Pontiac Late FX Series -7cc Flat Top Pontiac Late Forged Piston Set 4.190 inch bore COMP HEIGHT: 1.16
from $669.95
from $669.95
496 Pontiac Late , FX, Comp Height: 1.16, -7cc Flat Top , PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.500", ROD: 6.8, Approx Comp Ratio: 62cc-14.03, 87cc-10.86, 124cc-8.25
Choose Options
6150-4190 400 - 4.500 Stroke Pontiac Late FX Series -7cc Flat Top Pontiac Late Forged Piston Set 4.190 inch bore COMP HEIGHT: 1.16 6150-4190 400 - 4.500 Stroke Pontiac Late FX Series -7cc Flat Top Pontiac Late Forged Piston Set 4.190 inch bore COMP HEIGHT: 1.16
from $669.95
from $669.95
496 Pontiac Late , FX, Comp Height: 1.16, -7cc Flat Top , PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.500", ROD: 6.8, Approx Comp Ratio: 62cc-14.03, 87cc-10.86, 124cc-8.25
Choose Options
6150-4180 455 - 4.500 Stroke Pontiac Late FX Series -7cc Flat Top Pontiac Late Forged Piston Set 4.180 inch bore COMP HEIGHT: 1.16 6150-4180 455 - 4.500 Stroke Pontiac Late FX Series -7cc Flat Top Pontiac Late Forged Piston Set 4.180 inch bore COMP HEIGHT: 1.16
from $669.95
from $669.95
494 Pontiac Late , FX, Comp Height: 1.16, -7cc Flat Top , PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.500", ROD: 6.8, Approx Comp Ratio: 62cc-13.97, 87cc-10.83, 124cc-8.23
Choose Options
6150-4180 400 - 4.500 Stroke Pontiac Late FX Series -7cc Flat Top Pontiac Late Forged Piston Set 4.180 inch bore COMP HEIGHT: 1.16 6150-4180 400 - 4.500 Stroke Pontiac Late FX Series -7cc Flat Top Pontiac Late Forged Piston Set 4.180 inch bore COMP HEIGHT: 1.16
from $669.95
from $669.95
494 Pontiac Late , FX, Comp Height: 1.16, -7cc Flat Top , PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.500", ROD: 6.8, Approx Comp Ratio: 62cc-13.97, 87cc-10.83, 124cc-8.23
Choose Options
6150-4150 455 - 4.500 Stroke Pontiac Late FX Series -7cc Flat Top Pontiac Late Forged Piston Set 4.150 inch bore COMP HEIGHT: 1.16 6150-4150 455 - 4.500 Stroke Pontiac Late FX Series -7cc Flat Top Pontiac Late Forged Piston Set 4.150 inch bore COMP HEIGHT: 1.16
from $669.95
from $669.95
487 Pontiac Late , FX, Comp Height: 1.16, -7cc Flat Top , PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.500", ROD: 6.8, Approx Comp Ratio: 62cc-13.82, 87cc-10.69, 124cc-8.14
Choose Options
6150-4150 400 - 4.500 Stroke Pontiac Late FX Series -7cc Flat Top Pontiac Late Forged Piston Set 4.150 inch bore COMP HEIGHT: 1.16 6150-4150 400 - 4.500 Stroke Pontiac Late FX Series -7cc Flat Top Pontiac Late Forged Piston Set 4.150 inch bore COMP HEIGHT: 1.16
from $669.95
from $669.95
487 Pontiac Late , FX, Comp Height: 1.16, -7cc Flat Top , PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.500", ROD: 6.8, Approx Comp Ratio: 62cc-13.82, 87cc-10.69, 124cc-8.14
Choose Options
6146-4190 400 - 4.375 Stroke Pontiac Late FX Series -22cc Dish Top Pontiac Late Forged Piston Set 4.190 inch bore COMP HEIGHT: 1.222 6146-4190 400 - 4.375 Stroke Pontiac Late FX Series -22cc Dish Top Pontiac Late Forged Piston Set 4.190 inch bore COMP HEIGHT: 1.222
from $669.95
from $669.95
483 Pontiac Late , FX, Comp Height: 1.222, -22cc Dish Top, PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.375", ROD: 6.8, Approx Comp Ratio: 62cc-11.63, 87cc-9.39, 124cc-7.38
Choose Options
6146-4180 400 - 4.375 Stroke Pontiac Late FX Series -22cc Dish Top Pontiac Late Forged Piston Set 4.180 inch bore COMP HEIGHT: 1.222 6146-4180 400 - 4.375 Stroke Pontiac Late FX Series -22cc Dish Top Pontiac Late Forged Piston Set 4.180 inch bore COMP HEIGHT: 1.222
from $669.95
from $669.95
480 Pontiac Late , FX, Comp Height: 1.222, -22cc Dish Top, PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.375", ROD: 6.8, Approx Comp Ratio: 62cc-11.58, 87cc-9.33, 124cc-7.34
Choose Options
6146-4160 400 - 4.375 Stroke Pontiac Late FX Series -22cc Dish Top Pontiac Late Forged Piston Set 4.160 inch bore COMP HEIGHT: 1.222 6146-4160 400 - 4.375 Stroke Pontiac Late FX Series -22cc Dish Top Pontiac Late Forged Piston Set 4.160 inch bore COMP HEIGHT: 1.222
from $669.95
from $669.95
476 Pontiac Late , FX, Comp Height: 1.222, -22cc Dish Top, PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.375", ROD: 6.8, Approx Comp Ratio: 62cc-11.49, 87cc-9.28, 124cc-7.3
Choose Options
6146-4150 400 - 4.375 Stroke Pontiac Late FX Series -22cc Dish Top Pontiac Late Forged Piston Set 4.150 inch bore COMP HEIGHT: 1.222 6146-4150 400 - 4.375 Stroke Pontiac Late FX Series -22cc Dish Top Pontiac Late Forged Piston Set 4.150 inch bore COMP HEIGHT: 1.222
from $669.95
from $669.95
473 Pontiac Late , FX, Comp Height: 1.222, -22cc Dish Top, PIN: .99", Full-Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 4.375", ROD: 6.8, Approx Comp Ratio: 62cc-11.43, 87cc-9.22, 124cc-7.26
Choose Options
