L8T

L8T

Cylinder Bore Size Show all Cylinder Bore Size
With Rings \ Without Rings Show all With Rings \ Without Rings
Crankshaft Stroke Show all Crankshaft Stroke
Connecting Rod Length Show all Connecting Rod Length
Piston Pin Diameter Show all Piston Pin Diameter
Compression Height Show all Compression Height
Cylinder Head Type Show all Cylinder Head Type
Piston Series Show all Piston Series
TDC Assembly Height Show all TDC Assembly Height
Piston Top Aprox. Comp. Ratio Show all Piston Top Aprox. Comp. Ratio
K3-2766-4125 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.125 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.185 -20cc Dish Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.125 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-10.71, 65.5cc-10.04, 70cc-9.63
K3-2763-4065 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.065 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.185 -10cc Dish Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.125 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-11.68, 65.5cc-10.85, 70cc-10.35
K3-2776-4165 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.165 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -20cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-10.88, 65.5cc-10.20, 70cc-9.78
K3-2776-4185 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.185 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -20cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-10.96, 65.5cc-10.28, 70cc-9.85
K3-2776-4155 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.155 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -20cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-10.84, 65.5cc-10.16, 70cc-9.74
K3-2776-4130 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.130 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -20cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-10.73, 65.5cc-10.06, 70cc-9.65
K3-2776-4125 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.125 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -20cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-10.71, 65.5cc-10.04, 70cc-9.63
K3-2776-4070 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.070 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -20cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-10.48, 65.5cc-9.82, 70cc-9.42
K3-2776-4075 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.075 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -20cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-10.50, 65.5cc-9.84, 70cc-9.44
K3-2776-4065 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.065 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -20cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-10.46, 65.5cc-9.80, 70cc-9.40
K3-2773-4185 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.185 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -10cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-12.24, 65.5cc-11.37, 70cc-10.85
K3-2773-4130 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.130 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -10cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-11.98, 65.5cc-11.14, 70cc-10.62
K3-2773-4165 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.165 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -10cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-12.15, 65.5cc-11.29, 70cc-10.77
K3-2773-4155 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.155 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -10cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-12.10, 65.5cc-11.24, 70cc-10.73
K3-2773-4125 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.125 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -10cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-11.96, 65.5cc-11.11, 70cc-10.60
K3-2773-4075 L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.075 bore
$1,114.95
$1,114.95
L8T Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.210 -10cc Dish Pin: ,866 Ring Grooves: 1.2/1.2/3MM Stroke: 3.860 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-11.72, 65.5cc-10.90, 70cc-10.39
