Ford 460W 5.8 Stroker

REQUIRED FIELD: Choose Cyl Bore Size First Show all REQUIRED FIELD: Choose Cyl Bore Size First
Piston Top Aprox. Comp. Ratio Show all Piston Top Aprox. Comp. Ratio
Cylinder Head Show all Cylinder Head
Crankshaft Stroke Show all Crankshaft Stroke
Piston Pin Diameter Show all Piston Pin Diameter
Connecting Rod Length Show all Connecting Rod Length
Compression Height Show all Compression Height
Ring Groove Width Show all Ring Groove Width
3250-4000 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.000 inch bore COMP HEIGHT: 1.165 3250-4000 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.000 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
427 Small Block Ford 351W, FX, Comp Height: 1.165, -4cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-13.44, 64cc-12.48, 70cc-11.63
Choose Options
3250-4030 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.030 inch bore COMP HEIGHT: 1.165 3250-4030 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.030 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
434 Small Block Ford 351W, FX, Comp Height: 1.165, -4cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-13.65, 64cc-12.64, 70cc-11.79
Choose Options
3250-4040 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.040 inch bore COMP HEIGHT: 1.165 3250-4040 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.040 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
436 Small Block Ford 351W, FX, Comp Height: 1.165, -4cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-13.67, 64cc-12.7, 70cc-11.83
Choose Options
3250-4060 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.060 inch bore COMP HEIGHT: 1.165 3250-4060 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.060 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
440 Small Block Ford 351W, FX, Comp Height: 1.165, -4cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-13.79, 64cc-12.78, 70cc-11.93
Choose Options
3250-4125 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.125 inch bore COMP HEIGHT: 1.165 3250-4125 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.125 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
454 Small Block Ford 351W, FX, Comp Height: 1.165, -4cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-14.14, 64cc-13.13, 70cc-12.24
Choose Options
3250-4155 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.155 inch bore COMP HEIGHT: 1.165 3250-4155 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.155 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
461 Small Block Ford 351W, FX, Comp Height: 1.165, -4cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-14.31, 64cc-13.29, 70cc-12.39
Choose Options
3250-4165 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.165 inch bore COMP HEIGHT: 1.165 3250-4165 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.165 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
463 Small Block Ford 351W, FX, Comp Height: 1.165, -4cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-14.37, 64cc-13.34, 70cc-12.44
Choose Options
3250-4185 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.185 inch bore COMP HEIGHT: 1.165 3250-4185 434W - 5.8 Stroker Small Block Ford 351W FX Series -4cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.185 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
468 Small Block Ford 351W, FX, Comp Height: 1.165, -4cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-14.51, 64cc-13.45, 70cc-12.54
Choose Options
3251-4000 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.000 inch bore COMP HEIGHT: 1.165 3251-4000 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.000 inch bore COMP HEIGHT: 1.165
from $719.95
from $719.95
427 Small Block Ford 351W, FX, Comp Height: 1.165, -5cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-13.27, 64cc-12.33, 70cc-11.51
Choose Options
3251-4030 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.030 inch bore COMP HEIGHT: 1.165 3251-4030 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.030 inch bore COMP HEIGHT: 1.165
from $719.95
from $719.95
434 Small Block Ford 351W, FX, Comp Height: 1.165, -5cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-13.47, 64cc-12.49, 70cc-11.66
Choose Options
3251-4040 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.040 inch bore COMP HEIGHT: 1.165 3251-4040 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.040 inch bore COMP HEIGHT: 1.165
from $719.95
from $719.95
436 Small Block Ford 351W, FX, Comp Height: 1.165, -5cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-13.5, 64cc-12.55, 70cc-11.71
Choose Options
3251-4060 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.060 inch bore COMP HEIGHT: 1.165 3251-4060 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.060 inch bore COMP HEIGHT: 1.165
from $719.95
from $719.95
440 Small Block Ford 351W, FX, Comp Height: 1.165, -5cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-13.61, 64cc-12.63, 70cc-11.81
Choose Options
3251-4125 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.125 inch bore COMP HEIGHT: 1.165 3251-4125 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.125 inch bore COMP HEIGHT: 1.165
from $719.95
from $719.95
454 Small Block Ford 351W, FX, Comp Height: 1.165, -5cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-13.96, 64cc-12.97, 70cc-12.11
Choose Options
3251-4155 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.155 inch bore COMP HEIGHT: 1.165 3251-4155 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.155 inch bore COMP HEIGHT: 1.165
from $719.95
from $719.95
461 Small Block Ford 351W, FX, Comp Height: 1.165, -5cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-14.13, 64cc-13.13, 70cc-12.25
Choose Options
3251-4165 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.165 inch bore COMP HEIGHT: 1.165 3251-4165 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.165 inch bore COMP HEIGHT: 1.165
from $719.95
from $719.95
463 Small Block Ford 351W, FX, Comp Height: 1.165, -5cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-14.18, 64cc-13.16, 70cc-12.3
Choose Options
3251-4185 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.185 inch bore COMP HEIGHT: 1.165 3251-4185 434W - 5.8 Stroker Small Block Ford 351W FX Series -5cc Flat Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.185 inch bore COMP HEIGHT: 1.165
from $719.95
from $719.95
468 Small Block Ford 351W, FX, Comp Height: 1.165, -5cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.250", ROD: 6.2, Approx Comp Ratio: 58cc-14.33, 64cc-13.29, 70cc-12.4
Choose Options
