Small Block Chevy engine

Chevy 350

Clear all
Cylinder Bore Size Show all Cylinder Bore Size
With Rings \ Without Rings Show all With Rings \ Without Rings
Crankshaft Stroke Show all Crankshaft Stroke
Connecting Rod Length Show all Connecting Rod Length
Piston Pin Diameter Show all Piston Pin Diameter
Compression Height Show all Compression Height
Cylinder Head Type Show all Cylinder Head Type
Piston Series Show all Piston Series
TDC Assembly Height Show all TDC Assembly Height
Piston Top Aprox. Comp. Ratio Show all Piston Top Aprox. Comp. Ratio
1-2000-4000 350 Small Block Chevy 1-FX Series -5cc Flat Top Forged Piston Set. 4.000 bore 1-2000-4000 350 Small Block Chevy 1-FX Series -5cc Flat Top Forged Piston Set. 4.000 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" -5cc Flat Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.06, 64cc-10.28, 70cc-9.61
1-2000-4030 350 Small Block Chevy 1-FX Series -5cc Flat Top Forged Piston Set. 4.030 bore 1-2000-4030 350 Small Block Chevy 1-FX Series -5cc Flat Top Forged Piston Set. 4.030 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" -5cc Flat Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.19, 64cc-10.40, 70cc-9.72
1-2000-4040 350 Small Block Chevy 1-FX Series -5cc Flat Top Forged Piston Set. 4.040 bore 1-2000-4040 350 Small Block Chevy 1-FX Series -5cc Flat Top Forged Piston Set. 4.040 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" -5cc Flat Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.24, 64cc-10.45, 70cc-9.77
1-2000-4060 350 Small Block Chevy 1-FX Series -5cc Flat Top Forged Piston Set. 4.060 bore 1-2000-4060 350 Small Block Chevy 1-FX Series -5cc Flat Top Forged Piston Set. 4.060 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" -5cc Flat Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-11.32, 64cc-10.52, 70cc-9.83
1-2003-4000 350 Small Block Chevy 1-FX Series -13cc Dish Top Forged Piston Set. 4.000 bore 1-2003-4000 350 Small Block Chevy 1-FX Series -13cc Dish Top Forged Piston Set. 4.000 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" -13cc Dish Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-10.05, 64cc-9.41, 70cc-8.86
1-2003-4030 350 Small Block Chevy 1-FX Series -13cc Dish Top Forged Piston Set. 4.030 bore 1-2003-4030 350 Small Block Chevy 1-FX Series -13cc Dish Top Forged Piston Set. 4.030 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" -13cc Dish Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-10.16, 64cc-9.52, 70cc-8.96
1-2003-4040 350 Small Block Chevy 1-FX Series -13cc Dish Top Forged Piston Set. 4.040 bore 1-2003-4040 350 Small Block Chevy 1-FX Series -13cc Dish Top Forged Piston Set. 4.040 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" -13cc Dish Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-10.21, 64cc-9.56, 70cc-9.00
1-2003-4060 350 Small Block Chevy 1-FX Series -13cc Dish Top Forged Piston Set. 4.060 bore 1-2003-4060 350 Small Block Chevy 1-FX Series -13cc Dish Top Forged Piston Set. 4.060 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" -13cc Dish Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-10.28, 64cc-9.63, 70cc-9.06
1-2005-4000 350 Small Block Chevy 1-FX Series -21cc Dish Top Forged Piston Set. 4.000 bore 1-2005-4000 350 Small Block Chevy 1-FX Series -21cc Dish Top Forged Piston Set. 4.000 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" -21cc Dish Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-9.22, 64cc-8.69, 70cc-8.22
1-2005-4030 350 Small Block Chevy 1-FX Series -21cc Dish Top Forged Piston Set. 4.030 bore 1-2005-4030 350 Small Block Chevy 1-FX Series -21cc Dish Top Forged Piston Set. 4.030 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" -21cc Dish Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-9.32, 64cc-8.79, 70cc-8.32
1-2005-4040 350 Small Block Chevy 1-FX Series -21cc Dish Top Forged Piston Set. 4.040 bore 1-2005-4040 350 Small Block Chevy 1-FX Series -21cc Dish Top Forged Piston Set. 4.040 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" -21cc Dish Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-9.37, 64cc-8.83, 70cc-8.36
1-2005-4060 350 Small Block Chevy 1-FX Series -21cc Dish Top Forged Piston Set. 4.060 bore 1-2005-4060 350 Small Block Chevy 1-FX Series -21cc Dish Top Forged Piston Set. 4.060 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" -21cc Dish Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-9.43, 64cc-8.89, 70cc-8.41
1-2008-4000 350 Small Block Chevy 1-FX Series +4cc Dome Top Forged Piston Set. 4.000 bore 1-2008-4000 350 Small Block Chevy 1-FX Series +4cc Dome Top Forged Piston Set. 4.000 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" +4cc Dome Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-12.52, 64cc-11.51, 70cc-10.66
1-2008-4030 350 Small Block Chevy 1-FX Series +4cc Dome Top Forged Piston Set. 4.030 bore 1-2008-4030 350 Small Block Chevy 1-FX Series +4cc Dome Top Forged Piston Set. 4.030 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" +4cc Dome Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-12.66, 64cc-11.64, 70cc-10.78
1-2008-4040 350 Small Block Chevy 1-FX Series +4cc Dome Top Forged Piston Set. 4.040 bore 1-2008-4040 350 Small Block Chevy 1-FX Series +4cc Dome Top Forged Piston Set. 4.040 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" +4cc Dome Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-12.72, 64cc-11.69, 70cc-10.83
1-2008-4060 350 Small Block Chevy 1-FX Series +4cc Dome Top Forged Piston Set. 4.060 bore 1-2008-4060 350 Small Block Chevy 1-FX Series +4cc Dome Top Forged Piston Set. 4.060 bore
$669.95
$669.95
350 Small Block Chevy 1-FX Series 4032 Alloy Comp Hgt: 1.560" +4cc Dome Top Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.480" Rod: 5.700" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 58cc-12.80, 64cc-11.77, 70cc-10.90
