Wheels up Fox body Mustang with DSS Racing power.

Ford 347 - 3.400 Stroke

Cylinder Bore Size Show all Cylinder Bore Size
With Rings \ Without Rings Show all With Rings \ Without Rings
Crankshaft Stroke Show all Crankshaft Stroke
Connecting Rod Length Show all Connecting Rod Length
Piston Pin Diameter Show all Piston Pin Diameter
Compression Height Show all Compression Height
Cylinder Head Type Show all Cylinder Head Type
Piston Series Show all Piston Series
Piston Top Aprox. Comp. Ratio Show all Piston Top Aprox. Comp. Ratio
1-3110-4000-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4 inch bore 1-3110-4000-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4 inch bore
$669.95
$669.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 -22cc Dish Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-8.94, 64cc-8.43, 70cc-7.99
1-3110-4030-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.03 inch bore 1-3110-4030-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.03 inch bore
$669.95
$669.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 -22cc Dish Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-9.04, 64cc-8.53, 70cc-8.08
1-3110-4040-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.04 inch bore 1-3110-4040-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.04 inch bore
$669.95
$669.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 -22cc Dish Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-9.09, 64cc-8.57, 70cc-8.12
1-3110-4060-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.06 inch bore 1-3110-4060-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.06 inch bore
$669.95
$669.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 -22cc Dish Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-9.15, 64cc-8.63, 70cc-8.18
1-3110-4125-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.125 inch bore 1-3110-4125-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.125 inch bore
$669.95
$669.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 -22cc Dish Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-9.40, 64cc-8.87, 70cc-8.40
1-3110-4155-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.155 inch bore 1-3110-4155-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.155 inch bore
$669.95
$669.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 -22cc Dish Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-9.50, 64cc-8.97, 70cc-8.49
1-3110-4165-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.165 inch bore 1-3110-4165-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.165 inch bore
$669.95
$669.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 -22cc Dish Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-9.55, 64cc-9.01, 70cc-8.53
1-3110-4185-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.185 inch bore 1-3110-4185-347 Stroker-Small Block Ford 289 - 302 FX1 Series -22cc Dish Top SBF 20 Degree Inline & Twisted Wedge-Forged-Piston-Set- 4.185 inch bore
$669.95
$669.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 -22cc Dish Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-9.61, 64cc-9.06, 70cc-8.58
1-3116-4000-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4 inch bore 1-3116-4000-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4 inch bore
$719.95
$719.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 +6cc Dome Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-12.63, 64cc-11.58, 70cc-10.70
1-3116-4030-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.03 inch bore 1-3116-4030-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.03 inch bore
$719.95
$719.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 +6cc Dome Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-12.78, 64cc-11.71, 70cc-10.82
1-3116-4040-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.04 inch bore 1-3116-4040-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.04 inch bore
$719.95
$719.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 +6cc Dome Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-12.84, 64cc-11.77, 70cc-10.87
1-3116-4060-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.06 inch bore 1-3116-4060-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.06 inch bore
$719.95
$719.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 +6cc Dome Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-12.92, 64cc-11.85, 70cc-10.95
1-3116-4125-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.125 inch bore 1-3116-4125-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.125 inch bore
$719.95
$719.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 +6cc Dome Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-13.27, 64cc-12.17, 70cc-11.25
1-3116-4155-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.155 inch bore 1-3116-4155-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.155 inch bore
$719.95
$719.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 +6cc Dome Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-13.41, 64cc-12.30, 70cc-11.37
1-3116-4165-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.165 inch bore 1-3116-4165-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.165 inch bore
$719.95
$719.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 +6cc Dome Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-13.47, 64cc-12.36, 70cc-11.42
1-3116-4185-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.185 inch bore 1-3116-4185-347 Stroker-Small Block Ford 289 - 302 FX1 Series +6cc Dome Top SBF 20 Degree Inline-Forged-Piston-Set- 4.185 inch bore
$719.95
$719.95
347 Stroker Small Block Ford 289 - 302 FX Comp Height: 1.09 +6cc Dome Top PIN: .912 Ring Groove: 1.2/1.2/3MM Stroke: 3.4 ROD: 5.4 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Comp Ratio: 58cc-13.56, 64cc-12.43, 70cc-11.49
