LT1 6.2

LT1 6.2

Cylinder Bore Size Show all Cylinder Bore Size
With Rings \ Without Rings Show all With Rings \ Without Rings
Crankshaft Stroke Show all Crankshaft Stroke
Connecting Rod Length Show all Connecting Rod Length
Piston Pin Diameter Show all Piston Pin Diameter
Compression Height Show all Compression Height
Cylinder Head Type Show all Cylinder Head Type
Piston Series Show all Piston Series
TDC Assembly Height Show all TDC Assembly Height
Piston Top Aprox. Comp. Ratio Show all Piston Top Aprox. Comp. Ratio
K3-2754-4165 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.165 bore
$1,114.95
$1,114.95
LT1 6.8 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -12cc Dish Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-11.12, 65.5cc-10.36, 70cc-9.90
K3-2754-4070 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.070 bore
$1,114.95
$1,114.95
LT1 6.3 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -12cc Dish Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-10.71, 65.5cc-9.98, 70cc-9.53
K2-2754-4075 LT1 6.2 Chevy LT Direct Injection 2-FX Series 2618 Alloy Series Forged Piston Set.4.075 bore
$934.95
$934.95
LT1 6.4 Chevy LT Direct Injection 2-FX Series 2618 Alloy Comp Hgt: 1.33 -12cc Dish Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 59cc-10.73, 65.5cc-10.00, 70cc-9.55
K2-2754-4070 LT1 6.2 Chevy LT Direct Injection 2-FX Series 2618 Alloy Series Forged Piston Set.4.070 bore
$934.95
$934.95
LT1 6.3 Chevy LT Direct Injection 2-FX Series 2618 Alloy Comp Hgt: 1.33 -12cc Dish Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 59cc-10.71, 65.5cc-9.98, 70cc-9.53
K1-2741-4075 LT1 6.2 Chevy LT Direct Injection 1-FX Series 4032 Alloy Series Forged Piston Set.4.075 bore
$904.95
$904.95
LT1 6.4 Chevy LT Direct Injection 1-FX Series 4032 Alloy Comp Hgt: 1.305 -2cc Dome Pin: .927 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.125 Forged and Machined in Saint Charles Illinois USA! Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 59cc-12.13, 65.5cc-11.18, 70cc-10.61
K3-2751-4185 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.185 bore
$1,114.95
$1,114.95
LT1 6.9 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -2cc Dome Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-12.67, 65.5cc-11.68, 70cc-11.09
K3-2751-4155 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.155 bore
$1,114.95
$1,114.95
LT1 6.7 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -2cc Dome Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-12.52, 65.5cc-11.54, 70cc-10.95
K3-2751-4165 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.165 bore
$1,114.95
$1,114.95
LT1 6.8 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -2cc Dome Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-12.57, 65.5cc-11.59, 70cc-11.00
K3-2751-4130 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.130 bore
$1,114.95
$1,114.95
LT1 6.6 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -2cc Dome Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-12.39, 65.5cc-11.42, 70cc-10.84
K3-2751-4125 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.125 bore
$1,114.95
$1,114.95
LT1 6.5 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -2cc Dome Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-12.36, 65.5cc-11.40, 70cc-10.82
K3-2751-4075 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.075 bore
$1,114.95
$1,114.95
LT1 6.4 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -2cc Dome Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-12.13, 65.5cc-11.18, 70cc-10.61
K3-2751-4070 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.070 bore
$1,114.95
$1,114.95
LT1 6.3 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -2cc Dome Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-12.11, 65.5cc-11.16, 70cc-10.59
K3-2751-4065 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.065 bore
$1,114.95
$1,114.95
LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -2cc Dome Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-12.08, 65.5cc-11.13, 70cc-10.57
K3-2754-4185 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.185 bore
$1,114.95
$1,114.95
LT1 6.9 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -12cc Dish Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-11.21, 65.5cc-10.45, 70cc-9.98
K3-2754-4155 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.155 bore
$1,114.95
$1,114.95
LT1 6.7 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -12cc Dish Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-11.08, 65.5cc-10.32, 70cc-9.86
K3-2754-4130 LT1 6.2 Chevy LT Direct Injection 3-FX Series 2618 Alloy Series Forged Piston Set.4.130 bore
$1,114.95
$1,114.95
LT1 6.6 Chevy LT Direct Injection 3-FX Series 2618 Alloy Comp Hgt: 1.33 -12cc Dish Pin: .943 Ring Grooves: 1.2/1.2/3MM Stroke: 3.622 Rod: 6.098 Advanced Profile Precision Diamond-Turned Skirts Forged and Machined in Saint Charles Illinois USA! Aprox Comp Ratio: 59cc-10.96, 65.5cc-10.21, 70cc-9.76
