LS powered Camaro

Chevy LS

STEP 1: Choose Cyl Bore Size Show all STEP 1: Choose Cyl Bore Size
STEP 2: Piston Series Show all STEP 2: Piston Series
STEP 3: Connecting Rod Length Show all STEP 3: Connecting Rod Length
STEP 4: Piston Pin Diameter Show all STEP 4: Piston Pin Diameter
STEP 5: Cylinder Head Type Show all STEP 5: Cylinder Head Type
STEP 6: Top - Comp. Ratio Show all STEP 6: Top - Comp. Ratio
Compression Height Show all Compression Height
Crankshaft Stroke Show all Crankshaft Stroke
2870-4060 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.060 inch bore COMP HEIGHT: 1.215 2870-4060 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.060 inch bore COMP HEIGHT: 1.215
from $669.95
from $669.95
394 Chevy LS, FX, Comp Height: 1.215, -3cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.800", ROD: 6.125, Approx Comp Ratio: 64cc-11.68, 66cc-11.41, 72cc-10.68
Choose Options
2870-4040 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.040 inch bore COMP HEIGHT: 1.215 2870-4040 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.040 inch bore COMP HEIGHT: 1.215
from $669.95
from $669.95
390 Chevy LS, FX, Comp Height: 1.215, -3cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.800", ROD: 6.125, Approx Comp Ratio: 64cc-11.6, 66cc-11.33, 72cc-10.58
Choose Options
2870-4030 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.030 inch bore COMP HEIGHT: 1.215 2870-4030 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.030 inch bore COMP HEIGHT: 1.215
from $669.95
from $669.95
388 Chevy LS, FX, Comp Height: 1.215, -3cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.800", ROD: 6.125, Approx Comp Ratio: 64cc-11.54, 66cc-11.28, 72cc-10.53
Choose Options
2870-4005 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.005 inch bore COMP HEIGHT: 1.215 2870-4005 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.005 inch bore COMP HEIGHT: 1.215
from $669.95
from $669.95
383 Chevy LS, FX, Comp Height: 1.215, -3cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.800", ROD: 6.125, Approx Comp Ratio: 64cc-11.43, 66cc-11.16, 72cc-10.42
Choose Options
2870-4000 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.000 inch bore COMP HEIGHT: 1.215 2870-4000 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.000 inch bore COMP HEIGHT: 1.215
from $669.95
from $669.95
382 Chevy LS, FX, Comp Height: 1.215, -3cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.800", ROD: 6.125, Approx Comp Ratio: 64cc-11.4, 66cc-11.14, 72cc-10.4
Choose Options
2865-3913 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.913 inch bore COMP HEIGHT: 1.165 2865-3913 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.913 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
375 Chevy LS, FX, Comp Height: 1.165, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-8.61, 66cc-8.46, 72cc-8.06
Choose Options
2865-3903 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.903 inch bore COMP HEIGHT: 1.165 2865-3903 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.903 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
373 Chevy LS, FX, Comp Height: 1.165, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-8.58, 66cc-8.42, 72cc-8.02
Choose Options
2865-3898 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.898 inch bore COMP HEIGHT: 1.165 2865-3898 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.898 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
372 Chevy LS, FX, Comp Height: 1.165, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-8.56, 66cc-8.42, 72cc-8
Choose Options
2865-3840 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.840 inch bore COMP HEIGHT: 1.165 2865-3840 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.840 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
361 Chevy LS, FX, Comp Height: 1.165, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-8.35, 66cc-8.21, 72cc-7.81
Choose Options
2865-3820 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.820 inch bore COMP HEIGHT: 1.165 2865-3820 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.820 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
358 Chevy LS, FX, Comp Height: 1.165, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-8.3, 66cc-8.15, 72cc-7.76
Choose Options
2865-3810 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.810 inch bore COMP HEIGHT: 1.165 2865-3810 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.810 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
356 Chevy LS, FX, Comp Height: 1.165, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-8.26, 66cc-8.12, 72cc-7.72
Choose Options
2865-3785 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.785 inch bore COMP HEIGHT: 1.165 2865-3785 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.785 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
351 Chevy LS, FX, Comp Height: 1.165, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-8.17, 66cc-8.02, 72cc-7.64
Choose Options
2865-3780 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.780 inch bore COMP HEIGHT: 1.165 2865-3780 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.780 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
350 Chevy LS, FX, Comp Height: 1.165, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-8.15, 66cc-8, 72cc-7.62
Choose Options
2864-3913 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -22cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.913 inch bore COMP HEIGHT: 1.165 2864-3913 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -22cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.913 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
375 Chevy LS, FX, Comp Height: 1.165, -22cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-9.18, 66cc-9.01, 72cc-8.54
Choose Options
2864-3903 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -22cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.903 inch bore COMP HEIGHT: 1.165 2864-3903 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -22cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.903 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
373 Chevy LS, FX, Comp Height: 1.165, -22cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-9.14, 66cc-8.97, 72cc-8.51
Choose Options
2864-3840 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -22cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.840 inch bore COMP HEIGHT: 1.165 2864-3840 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS FX Series -22cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.840 inch bore COMP HEIGHT: 1.165
from $669.95
from $669.95
361 Chevy LS, FX, Comp Height: 1.165, -22cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-8.9, 66cc-8.74, 72cc-8.28
Choose Options
