PART #: 8863-4000

8863-4000 347 Stroker Small Block Ford 289 - 302 SX Series -18cc Dish Top SBF 20 Degree Inline & Twisted Wedge Forged Piston Set 4.000 inch bore

Regular price $599.95
Sale price $599.95 Regular price
Sale Sold out
Unit price
/per
Ships in 1 - 8 days

Ships in 1 - 8 days

Made in the USA

Made in the USA

Secure Payment

Secure Payment

Piston & Ring Kit Option:
This is a pre order item. We will ship it when it comes in stock.

342 Small Block Ford 289 - 302, SX 4032 Alloy, Comp Height: 1.09, -18cc Dish Top, PIN: .912", Full Floating or Press Fit, Ring Groove: 1/16-1/16-3/16" , Stroke: 3.400", ROD: 5.4, Approx Comp Ratio: 58cc-9.32, 64cc-8.76, 70cc-8.28


Engine Brand: Ford

Engine Family: Small Block Ford 289 - 302

Engine Size: 347 Stroker

With/Without Rings: Without Rings

Cylinder Bore Size: 4.000 in , 101.520 mm

Ring Width: 1/16-1/16-3/16"

Compression Height: 1.090"

Pin Diameter: 0.912"

Connecting Rod Length: 5.400"

Crankshaft Stroke: 3.400"

Piston Series: SX 4032 Alloy

Alloy: 4032 Alloy

Cylinder Head: SBF 20 Degree Inline & Twisted Wedge

TDC Assembly Height: 8.190"

Piston Top Aprox. Comp. Ratio:

-18cc Dish Top SBF 20 Degree Inline & Twisted Wedge
ChamberComp Ratio
589.32 to 1
648.76 to 1
708.28 to 1

Download Piston Instructions


Features: Piston Series


E series

 SX series  1-FX series  2-FX series  3-FX series
Broached pin oiling slots

x

x







Drilled, forced wrist pin oiling



x

x

x

x

Forged drain-back windows

x









Drilled bottom ring land intersecting oil groove drain-backs



x

x

x

x

Slightly larger, deeper valve reliefs than OEM

x









CNC machined valve reliefs for moderate performance heads and cam combinations



x

Larger, deeper CNC valve reliefs for more aggressive cylinder head and cam combinations





x

x

x

Premium Aircraft spec. 4032 low expansion alloy

x

x

x





Premium Aircraft spec. 2618 alloy







x

x

Blower, Turbo, NOS ready



x

x

x

x

Brushed piston crown





x

x

x

Turned dishs

x

x







Max Quench milled dishs





x

x

x

Additional CNC milling for weight reduction in non-critical areas





x

x

x

Patented “X Groove” skirt for superior cylinder and ring life





x

x

x

Thinner/shallower Ring grooves for maximum ring seal and land strength





x

x

x

Low volume contact reduction grooves

x

x

x

2nd ring land accumulator groove prevents ring flutter

x

x

x

3rd ring land scraper relief

x

x

x

Oil ring groove relief reservoir

x

x

x

Inner and outer pin boss weight reduction radiusing

x

x

x

Tighter control of crown thickness yields consistently lighter parts

x

x

x

Dynamic skirt milling controls skirt thickness for consistently lighter parts



x

x

x

Diamond-turned high strength skirts

x

x

x

x

x

High-strength piston pins

x

x

x

x

x

Extreme Duty XR wrist pins



x

Horizontal Gas Ports enhance ring seal

x

Forged and machined in the USA

x

x

x

x

x

Piston Specs

Engine Brand: Ford

Engine Family: Small Block Ford 289 - 302

Engine Size: 347 Stroker

With/Without Rings: Without Rings

Cylinder Bore Size: 4.000 in , 101.520 mm

Ring Width: 1/16-1/16-3/16"

Compression Height: 1.090"

Pin Diameter: 0.912"

Connecting Rod Length: 5.400"

Crankshaft Stroke: 3.400"

Piston Series: SX 4032 Alloy

Alloy: 4032 Alloy

Cylinder Head: SBF 20 Degree Inline & Twisted Wedge

TDC Assembly Height: 8.190"

Piston Top Aprox. Comp. Ratio:

-18cc Dish Top SBF 20 Degree Inline & Twisted Wedge
ChamberComp Ratio
589.32 to 1
648.76 to 1
708.28 to 1

Download Piston Instructions
