PART #: 1-6810-4090

6810-4090 426 - 6.2 - 6.4 Stroker Small Block Mopar Hemi Gen III FX Series -1.5cc Flat Top Gen III Hemi Forged Piston Set 4.090 inch bore Pin Dia.: 0.927" Comp Height: 1.12"

Regular price $669.95
Sale price $669.95 Regular price
Sale Sold out
Unit price
/per
Piston Series Option:
Piston Ring Kit Option:
Ships in 1 - 8 days

Ships in 1 - 8 days

Made in the USA

Made in the USA

Secure Payment

Secure Payment

This is a pre order item. We will ship it when it comes in stock.

426 Small Block Mopar Hemi Gen III, FX, Comp Height: 1.12, -1.5cc Flat Top , PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.050", ROD: 6.125, Approx Comp Ratio: 65cc-12.55, 74cc-11.32, 85cc-10.13


Piston Top Aprox. Comp. Ratio:

-1.5cc Flat Top Gen III Hemi
ChamberComp Ratio
6512.55 to 1
7411.32 to 1
8510.13 to 1

For accurate Comp Ratio info use the calculator below.

Engine Brand: Mopar

Engine Family: Small Block Mopar Hemi Gen III

Engine Size: 426 - 6.2 - 6.4 Stroker

Cylinder Bore Size: 4.090 in , 103.804 mm

Ring Groove Width: 1.2/1.2/3MM

Compression Height: 1.120"

Pin Diameter: 0.927"

Connecting Rod Length: 6.125"

Crankshaft Stroke: 4.050"

Cylinder Head: Gen III Hemi

TDC Assembly Height: 9.270" ( Zero Deck Height )

Download Piston Instructions


Features: Piston Series


E series

 SX series  1-FX series  2-FX series  3-FX series
Broached pin oiling slots

x

x







Drilled, forced wrist pin oiling



x

x

x

x

Forged drain-back windows

x









Drilled bottom ring land intersecting oil groove drain-backs



x

x

x

x

Slightly larger, deeper valve reliefs than OEM

x









CNC machined valve reliefs for moderate performance heads and cam combinations



x

Larger, deeper CNC valve reliefs for more aggressive cylinder head and cam combinations





x

x

x

Premium Aircraft spec. 4032 low expansion alloy

x

x

x





Premium Aircraft spec. 2618 alloy







x

x

Blower, Turbo, NOS ready



x

x

x

x

Brushed piston crown





x

x

x

Turned dishs

x

x







Max Quench milled dishs





x

x

x

Additional CNC milling for weight reduction in non-critical areas





x

x

x

Patented “X Groove” skirt for superior cylinder and ring life





x

x

x

Thinner/shallower Ring grooves for maximum ring seal and land strength





x

x

x

Low volume contact reduction grooves

x

x

x

2nd ring land accumulator groove prevents ring flutter

x

x

x

3rd ring land scraper relief

x

x

x

Oil ring groove relief reservoir

x

x

x

Inner and outer pin boss weight reduction radiusing

x

x

x

Tighter control of crown thickness yields consistently lighter parts

x

x

x

Dynamic skirt milling controls skirt thickness for consistently lighter parts



x

x

x

Diamond-turned high strength skirts

x

x

x

x

x

High-strength piston pins

x

x

x

x

x

Extreme Duty XR wrist pins



x

Horizontal Gas Ports enhance ring seal

x

Forged and machined in the USA

x

x

x

x

x

Piston Specs

Piston Top Aprox. Comp. Ratio:

-1.5cc Flat Top Gen III Hemi
ChamberComp Ratio
6512.55 to 1
7411.32 to 1
8510.13 to 1

For accurate Comp Ratio info use the calculator below.

Engine Brand: Mopar

Engine Family: Small Block Mopar Hemi Gen III

Engine Size: 426 - 6.2 - 6.4 Stroker

Cylinder Bore Size: 4.090 in , 103.804 mm

Ring Groove Width: 1.2/1.2/3MM

Compression Height: 1.120"

Pin Diameter: 0.927"

Connecting Rod Length: 6.125"

Crankshaft Stroke: 4.050"

Cylinder Head: Gen III Hemi

TDC Assembly Height: 9.270" ( Zero Deck Height )

Download Piston Instructions

Piston Series Comparison Chart

Features: Piston Series


E series

 SX series  1-FX series  2-FX series  3-FX series
Broached pin oiling slots

x

x







Drilled, forced wrist pin oiling



x

x

x

x

Forged drain-back windows

x









Drilled bottom ring land intersecting oil groove drain-backs



x

x

x

x

Slightly larger, deeper valve reliefs than OEM

x









CNC machined valve reliefs for moderate performance heads and cam combinations



x

Larger, deeper CNC valve reliefs for more aggressive cylinder head and cam combinations





x

x

x

Premium Aircraft spec. 4032 low expansion alloy

x

x

x





Premium Aircraft spec. 2618 alloy







x

x

Blower, Turbo, NOS ready



x

x

x

x

Brushed piston crown





x

x

x

Turned dishs

x

x







Max Quench milled dishs





x

x

x

Additional CNC milling for weight reduction in non-critical areas





x

x

x

Patented “X Groove” skirt for superior cylinder and ring life





x

x

x

Thinner/shallower Ring grooves for maximum ring seal and land strength





x

x

x

Low volume contact reduction grooves

x

x

x

2nd ring land accumulator groove prevents ring flutter

x

x

x

3rd ring land scraper relief

x

x

x

Oil ring groove relief reservoir

x

x

x

Inner and outer pin boss weight reduction radiusing

x

x

x

Tighter control of crown thickness yields consistently lighter parts

x

x

x

Dynamic skirt milling controls skirt thickness for consistently lighter parts



x

x

x

Diamond-turned high strength skirts

x

x

x

x

x

High-strength piston pins

x

x

x

x

x

Extreme Duty XR wrist pins



x

Horizontal Gas Ports enhance ring seal

x

Forged and machined in the USA

x

x

x

x

x
