Wheels up Fox body Mustang with DSS Racing power.

Ford 289 302 5.0

REQUIRED FIELD: Choose Cyl Bore Size First Show all REQUIRED FIELD: Choose Cyl Bore Size First
Cylinder Head Show all Cylinder Head
Crankshaft Stroke Show all Crankshaft Stroke
Piston Pin Diameter Show all Piston Pin Diameter
Connecting Rod Length Show all Connecting Rod Length
Compression Height Show all Compression Height
Piston Top Aprox. Comp. Ratio Show all Piston Top Aprox. Comp. Ratio
8720-4040 302 - 5.0 Small Block Ford 302 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.040 inch bore 8720-4040 302 - 5.0 Small Block Ford 302 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.040 inch bore
from $409.95
from $409.95
308 Small Block Ford 302, E 4032 Alloy, Comp Height: 1.6, -3cc Flat Top , PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 3.000", ROD: 5.09, Approx Comp Ratio: 58cc-10.1, 64cc-9.37, 70cc-8.75
Choose Options
8720-4040 302 - 5.0 Small Block Ford 302 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.040 inch bore COMP HEIGHT: 1.6 8720-4040 302 - 5.0 Small Block Ford 302 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.040 inch bore COMP HEIGHT: 1.6
from $409.95
from $409.95
308 Small Block Ford 302, E, Comp Height: 1.6, -3cc Flat Top , PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 3.000", ROD: 5.09, Approx Comp Ratio: 58cc-10.1, 64cc-9.37, 70cc-8.75
Choose Options
8720-4040C 289 Small Block Ford 289 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.040 inch bore 8720-4040C 289 Small Block Ford 289 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.040 inch bore
$409.95
$409.95
294 Small Block Ford 289, E 4032 Alloy, Comp Height: 1.6, -3cc Flat Top, PIN: .912, Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16", Stroke: 2.87, ROD: 5.155, , Appox Comp Ratio: 58cc-9.69, 64cc-8.99, 70cc-8.39
8720-4060 289 Small Block Ford 289 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.060 inch bore 8720-4060 289 Small Block Ford 289 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.060 inch bore
from $409.95
from $409.95
297 Small Block Ford 289, E 4032 Alloy, Comp Height: 1.6, -3cc Flat Top , PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 2.870", ROD: 5.155, Approx Comp Ratio: 58cc-9.76, 64cc-9.05, 70cc-8.47
Choose Options
8720-4060 289 Small Block Ford 289 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.060 inch bore COMP HEIGHT: 1.6 8720-4060 289 Small Block Ford 289 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.060 inch bore COMP HEIGHT: 1.6
from $409.95
from $409.95
297 Small Block Ford 289, E, Comp Height: 1.6, -3cc Flat Top , PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 2.870", ROD: 5.155, Approx Comp Ratio: 58cc-9.76, 64cc-9.05, 70cc-8.47
Choose Options
8720-4060 302 - 5.0 Small Block Ford 302 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.060 inch bore 8720-4060 302 - 5.0 Small Block Ford 302 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.060 inch bore
from $409.95
from $409.95
311 Small Block Ford 302, E 4032 Alloy, Comp Height: 1.6, -3cc Flat Top , PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 3.000", ROD: 5.09, Approx Comp Ratio: 58cc-10.17, 64cc-9.43, 70cc-8.82
Choose Options
8720-4060 302 - 5.0 Small Block Ford 302 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.060 inch bore COMP HEIGHT: 1.6 8720-4060 302 - 5.0 Small Block Ford 302 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.060 inch bore COMP HEIGHT: 1.6
from $409.95
from $409.95
311 Small Block Ford 302, E, Comp Height: 1.6, -3cc Flat Top , PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 3.000", ROD: 5.09, Approx Comp Ratio: 58cc-10.17, 64cc-9.43, 70cc-8.82
Choose Options
8720-4060C 289 Small Block Ford 289 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.060 inch bore 8720-4060C 289 Small Block Ford 289 E Series -3cc Flat Top SBF 20 Degree Inline Forged Piston Set 4.060 inch bore
$409.95
$409.95
297 Small Block Ford 289, E 4032 Alloy, Comp Height: 1.6, -3cc Flat Top, PIN: .912, Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16", Stroke: 2.87, ROD: 5.155, , Appox Comp Ratio: 58cc-9.76, 64cc-9.05, 70cc-8.47
8723-4000 289 Small Block Ford 289 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.000 inch bore 8723-4000 289 Small Block Ford 289 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.000 inch bore
from $409.95
from $409.95
289 Small Block Ford 289, E 4032 Alloy, Comp Height: 1.6, -13cc Dish Top, PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 2.870", ROD: 5.155, Approx Comp Ratio: 58cc-8.46, 64cc-7.95, 70cc-7.49
Choose Options
8723-4000 289 Small Block Ford 289 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.000 inch bore COMP HEIGHT: 1.6 8723-4000 289 Small Block Ford 289 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.000 inch bore COMP HEIGHT: 1.6
from $409.95
from $409.95
289 Small Block Ford 289, E, Comp Height: 1.6, -13cc Dish Top, PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 2.870", ROD: 5.155, Approx Comp Ratio: 58cc-8.46, 64cc-7.95, 70cc-7.49
Choose Options
8723-4000 302 - 5.0 Small Block Ford 302 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.000 inch bore 8723-4000 302 - 5.0 Small Block Ford 302 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.000 inch bore
from $409.95
from $409.95
302 Small Block Ford 302, E 4032 Alloy, Comp Height: 1.6, -13cc Dish Top, PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 3.000", ROD: 5.09, Approx Comp Ratio: 58cc-8.8, 64cc-8.26, 70cc-7.78
Choose Options
8723-4000 302 - 5.0 Small Block Ford 302 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.000 inch bore COMP HEIGHT: 1.6 8723-4000 302 - 5.0 Small Block Ford 302 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.000 inch bore COMP HEIGHT: 1.6
from $409.95
from $409.95
302 Small Block Ford 302, E, Comp Height: 1.6, -13cc Dish Top, PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 3.000", ROD: 5.09, Approx Comp Ratio: 58cc-8.8, 64cc-8.26, 70cc-7.78
Choose Options
8723-4000C 289 Small Block Ford 289 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.000 inch bore 8723-4000C 289 Small Block Ford 289 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.000 inch bore
$409.95
$409.95
289 Small Block Ford 289, E 4032 Alloy, Comp Height: 1.6, -13cc Dish Top, PIN: .912, Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16", Stroke: 2.87, ROD: 5.155, , Appox Comp Ratio: 58cc-8.46, 64cc-7.95, 70cc-7.49
8723-4030 289 Small Block Ford 289 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.030 inch bore 8723-4030 289 Small Block Ford 289 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.030 inch bore
from $409.95
from $409.95
293 Small Block Ford 289, E 4032 Alloy, Comp Height: 1.6, -13cc Dish Top, PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 2.870", ROD: 5.155, Approx Comp Ratio: 58cc-8.57, 64cc-8.03, 70cc-7.58
Choose Options
8723-4030 289 Small Block Ford 289 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.030 inch bore COMP HEIGHT: 1.6 8723-4030 289 Small Block Ford 289 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.030 inch bore COMP HEIGHT: 1.6
from $409.95
from $409.95
293 Small Block Ford 289, E, Comp Height: 1.6, -13cc Dish Top, PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 2.870", ROD: 5.155, Approx Comp Ratio: 58cc-8.57, 64cc-8.03, 70cc-7.58
Choose Options
8723-4030 302 - 5.0 Small Block Ford 302 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.030 inch bore 8723-4030 302 - 5.0 Small Block Ford 302 E Series -13cc Dish Top SBF 20 Degree Inline Forged Piston Set 4.030 inch bore
from $409.95
from $409.95
306 Small Block Ford 302, E 4032 Alloy, Comp Height: 1.6, -13cc Dish Top, PIN: .912", Full-Floating or Press Fit, Ring Groove: 5/64-5/64-3/16" , Stroke: 3.000", ROD: 5.09, Approx Comp Ratio: 58cc-8.9, 64cc-8.34, 70cc-7.87
Choose Options
