LS powered Camaro

Chevy LS

REQUIRED FIELD: Choose Cyl Bore Size First Show all REQUIRED FIELD: Choose Cyl Bore Size First
Cylinder Head Show all Cylinder Head
Crankshaft Stroke Show all Crankshaft Stroke
Piston Pin Diameter Show all Piston Pin Diameter
Connecting Rod Length Show all Connecting Rod Length
Compression Height Show all Compression Height
Piston Top Aprox. Comp. Ratio Show all Piston Top Aprox. Comp. Ratio
1885-4165 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS SX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.165 inch bore COMP HEIGHT: 1.165 1885-4165 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS SX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.165 inch bore COMP HEIGHT: 1.165
from $599.95
from $599.95
425 Chevy LS, SX, Comp Height: 1.165, -29cc Dish Top, PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-9.54, 66cc-9.38, 72cc-8.92
Choose Options
1885-4185 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS SX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.185 inch bore COMP HEIGHT: 1.165 1885-4185 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS SX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.185 inch bore COMP HEIGHT: 1.165
from $599.95
from $599.95
429 Chevy LS, SX, Comp Height: 1.165, -29cc Dish Top, PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 3.900", ROD: 6.125, Approx Comp Ratio: 64cc-9.61, 66cc-9.44, 72cc-8.99
Choose Options
1900-3780 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.780 inch bore COMP HEIGHT: 1.115 1900-3780 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.780 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
359 Chevy LS, SX, Comp Height: 1.115, -3cc Flat Top , PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-10.88, 66cc-10.63, 72cc-9.92
Choose Options
1900-3785 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.785 inch bore COMP HEIGHT: 1.115 1900-3785 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.785 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
360 Chevy LS, SX, Comp Height: 1.115, -3cc Flat Top , PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-10.91, 66cc-10.66, 72cc-9.95
Choose Options
1900-3810 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.810 inch bore COMP HEIGHT: 1.115 1900-3810 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.810 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
365 Chevy LS, SX, Comp Height: 1.115, -3cc Flat Top , PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-11.05, 66cc-10.77, 72cc-10.07
Choose Options
1900-3820 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.820 inch bore COMP HEIGHT: 1.115 1900-3820 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.820 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
367 Chevy LS, SX, Comp Height: 1.115, -3cc Flat Top , PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-11.08, 66cc-10.82, 72cc-10.12
Choose Options
1900-3840 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.840 inch bore COMP HEIGHT: 1.115 1900-3840 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.840 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
371 Chevy LS, SX, Comp Height: 1.115, -3cc Flat Top , PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-11.19, 66cc-10.93, 72cc-10.2
Choose Options
1900-3898 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.898 inch bore COMP HEIGHT: 1.115 1900-3898 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.898 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
382 Chevy LS, SX, Comp Height: 1.115, -3cc Flat Top , PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-11.45, 66cc-11.18, 72cc-10.46
Choose Options
1900-3903 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.903 inch bore COMP HEIGHT: 1.115 1900-3903 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.903 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
383 Chevy LS, SX, Comp Height: 1.115, -3cc Flat Top , PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-11.48, 66cc-11.21, 72cc-10.46
Choose Options
1900-3913 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.913 inch bore COMP HEIGHT: 1.115 1900-3913 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -3cc Flat Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.913 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
385 Chevy LS, SX, Comp Height: 1.115, -3cc Flat Top , PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-11.53, 66cc-11.26, 72cc-10.51
Choose Options
1901-3780 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -10cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.780 inch bore COMP HEIGHT: 1.115 1901-3780 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -10cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.780 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
359 Chevy LS, SX, Comp Height: 1.115, -10cc Dish Top, PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-10.05, 66cc-9.82, 72cc-9.23
Choose Options
1901-3785 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -10cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.785 inch bore COMP HEIGHT: 1.115 1901-3785 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -10cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.785 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
360 Chevy LS, SX, Comp Height: 1.115, -10cc Dish Top, PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-10.05, 66cc-9.84, 72cc-9.26
Choose Options
1901-3810 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -10cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.810 inch bore COMP HEIGHT: 1.115 1901-3810 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -10cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.810 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
365 Chevy LS, SX, Comp Height: 1.115, -10cc Dish Top, PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-10.18, 66cc-9.96, 72cc-9.36
Choose Options
1901-3820 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -10cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.820 inch bore COMP HEIGHT: 1.115 1901-3820 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -10cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.820 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
367 Chevy LS, SX, Comp Height: 1.115, -10cc Dish Top, PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-10.23, 66cc-10, 72cc-9.4
Choose Options
1901-3840 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -10cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.840 inch bore COMP HEIGHT: 1.115 1901-3840 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -10cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.840 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
371 Chevy LS, SX, Comp Height: 1.115, -10cc Dish Top, PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-10.31, 66cc-10.09, 72cc-9.48
Choose Options
1901-3898 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -10cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.898 inch bore COMP HEIGHT: 1.115 1901-3898 4.8 - 5.3 - LS1 - LS6 - Stroker Chevy LS SX Series -10cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.898 inch bore COMP HEIGHT: 1.115
from $599.95
from $599.95
382 Chevy LS, SX, Comp Height: 1.115, -10cc Dish Top, PIN: .927", Full Floating or Press Fit, Ring Groove: 1.5/1.5/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-10.57, 66cc-10.34, 72cc-9.71
Choose Options
