Chevy 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - 7.0 - LS7 - LSX 4.000

Chevy 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - 7.0 - LS7 - LSX 4.000" Stroke

REQUIRED FIELD: Choose Cyl Bore Size First Show all REQUIRED FIELD: Choose Cyl Bore Size First
Cylinder Head Show all Cylinder Head
Crankshaft Stroke Show all Crankshaft Stroke
Piston Pin Diameter Show all Piston Pin Diameter
Connecting Rod Length Show all Connecting Rod Length
Compression Height Show all Compression Height
Piston Top Aprox. Comp. Ratio Show all Piston Top Aprox. Comp. Ratio
2924-4155 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -22cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.155 inch bore COMP HEIGHT: 1.115 2924-4155 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -22cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.155 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
434 Chevy LS, FX, Comp Height: 1.115, -22cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-10.37, 66cc-10.18, 72cc-9.64
Choose Options
2924-4165 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -22cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.165 inch bore COMP HEIGHT: 1.115 2924-4165 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -22cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.165 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
436 Chevy LS, FX, Comp Height: 1.115, -22cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-10.41, 66cc-10.22, 72cc-9.68
Choose Options
2924-4185 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -22cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.185 inch bore COMP HEIGHT: 1.115 2924-4185 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -22cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.185 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
440 Chevy LS, FX, Comp Height: 1.115, -22cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-10.48, 66cc-10.29, 72cc-9.74
Choose Options
2925-4000 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.000 inch bore COMP HEIGHT: 1.115 2925-4000 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.000 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
402 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.13, 66cc-8.98, 72cc-8.53
Choose Options
2925-4005 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.005 inch bore COMP HEIGHT: 1.115 2925-4005 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.005 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
403 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.15, 66cc-9, 72cc-8.55
Choose Options
2925-4030 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.030 inch bore COMP HEIGHT: 1.115 2925-4030 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.030 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
408 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.24, 66cc-9.08, 72cc-8.65
Choose Options
2925-4040 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.040 inch bore COMP HEIGHT: 1.115 2925-4040 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.040 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
410 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.28, 66cc-9.12, 72cc-8.67
Choose Options
2925-4060 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.060 inch bore COMP HEIGHT: 1.115 2925-4060 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.060 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
414 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.36, 66cc-9.2, 72cc-8.75
Choose Options
2925-4065 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.065 inch bore COMP HEIGHT: 1.115 2925-4065 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.065 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
415 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.38, 66cc-9.21, 72cc-8.77
Choose Options
2925-4070 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.070 inch bore COMP HEIGHT: 1.115 2925-4070 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.070 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
416 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.39, 66cc-9.23, 72cc-8.78
Choose Options
2925-4075 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.075 inch bore COMP HEIGHT: 1.115 2925-4075 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.075 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
417 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.41, 66cc-9.25, 72cc-8.8
Choose Options
2925-4125 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.125 inch bore COMP HEIGHT: 1.115 2925-4125 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.125 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
428 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.62, 66cc-9.45, 72cc-8.99
Choose Options
2925-4130 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.130 inch bore COMP HEIGHT: 1.115 2925-4130 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.130 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
429 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.64, 66cc-9.47, 72cc-9
Choose Options
2925-4155 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.155 inch bore COMP HEIGHT: 1.115 2925-4155 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.155 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
434 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.72, 66cc-9.56, 72cc-9.08
Choose Options
2925-4165 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.165 inch bore COMP HEIGHT: 1.115 2925-4165 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.165 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
436 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.76, 66cc-9.6, 72cc-9.12
Choose Options
2925-4185 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.185 inch bore COMP HEIGHT: 1.115 2925-4185 6.0 - LS2 -6.2 - LS3 - L98 - LQ9 - LS7 - LSA - LSX Stroker Chevy LS FX Series -29cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 4.185 inch bore COMP HEIGHT: 1.115
from $669.95
from $669.95
440 Chevy LS, FX, Comp Height: 1.115, -29cc Dish Top, PIN: .927", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 4.000", ROD: 6.125, Approx Comp Ratio: 64cc-9.83, 66cc-9.66, 72cc-9.2
Choose Options
