LS powered Camaro

Chevy 4.8 - 5.3 - 5.7 - LS1 - LS6 OEM 3.622" Stroke

REQUIRED FIELD: Choose Cyl Bore Size First Show all REQUIRED FIELD: Choose Cyl Bore Size First
Cylinder Head Show all Cylinder Head
Crankshaft Stroke Show all Crankshaft Stroke
Piston Pin Diameter Show all Piston Pin Diameter
Connecting Rod Length Show all Connecting Rod Length
Compression Height Show all Compression Height
Piston Top Aprox. Comp. Ratio Show all Piston Top Aprox. Comp. Ratio
2812-3780 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.780 inch bore COMP HEIGHT: 1.33 2812-3780 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.780 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
325 Chevy LS, FX, Comp Height: 1.33, +6cc Dome Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-11.18, 66cc-10.88, 72cc-10.07
Choose Options
2812-3785 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.785 inch bore COMP HEIGHT: 1.33 2812-3785 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.785 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
326 Chevy LS, FX, Comp Height: 1.33, +6cc Dome Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-11.21, 66cc-10.91, 72cc-10.1
Choose Options
2812-3810 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.810 inch bore COMP HEIGHT: 1.33 2812-3810 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.810 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
330 Chevy LS, FX, Comp Height: 1.33, +6cc Dome Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-11.31, 66cc-11.01, 72cc-10.21
Choose Options
2812-3820 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.820 inch bore COMP HEIGHT: 1.33 2812-3820 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.820 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
332 Chevy LS, FX, Comp Height: 1.33, +6cc Dome Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-11.380, 66cc-11.07, 72cc-10.24
Choose Options
2812-3840 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.840 inch bore COMP HEIGHT: 1.33 2812-3840 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.840 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
336 Chevy LS, FX, Comp Height: 1.33, +6cc Dome Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-11.5, 66cc-11.19, 72cc-10.35
Choose Options
2812-3898 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.898 inch bore COMP HEIGHT: 1.33 2812-3898 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.898 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
346 Chevy LS, FX, Comp Height: 1.33, +6cc Dome Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-11.76, 66cc-11.45, 72cc-10.61
Choose Options
2812-3903 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.903 inch bore COMP HEIGHT: 1.33 2812-3903 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.903 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
347 Chevy LS, FX, Comp Height: 1.33, +6cc Dome Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-11.79, 66cc-11.48, 72cc-10.62
Choose Options
2812-3913 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.913 inch bore COMP HEIGHT: 1.33 2812-3913 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series +6cc Dome Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.913 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
348 Chevy LS, FX, Comp Height: 1.33, +6cc Dome Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-11.82, 66cc-11.51, 72cc-10.65
Choose Options
2813-3780 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.780 inch bore COMP HEIGHT: 1.33 2813-3780 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.780 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
325 Chevy LS, FX, Comp Height: 1.33, -15cc Dish Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-8.71, 66cc-8.54, 72cc-8.05
Choose Options
2813-3785 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.785 inch bore COMP HEIGHT: 1.33 2813-3785 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.785 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
326 Chevy LS, FX, Comp Height: 1.33, -15cc Dish Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-8.73, 66cc-8.56, 72cc-8.07
Choose Options
2813-3810 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.810 inch bore COMP HEIGHT: 1.33 2813-3810 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.810 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
330 Chevy LS, FX, Comp Height: 1.33, -15cc Dish Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-8.81, 66cc-8.64, 72cc-8.16
Choose Options
2813-3820 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.820 inch bore COMP HEIGHT: 1.33 2813-3820 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.820 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
332 Chevy LS, FX, Comp Height: 1.33, -15cc Dish Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-8.86, 66cc-8.69, 72cc-8.19
Choose Options
2813-3840 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.840 inch bore COMP HEIGHT: 1.33 2813-3840 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.840 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
336 Chevy LS, FX, Comp Height: 1.33, -15cc Dish Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-8.95, 66cc-8.76, 72cc-8.28
Choose Options
2813-3898 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.898 inch bore COMP HEIGHT: 1.33 2813-3898 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.898 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
346 Chevy LS, FX, Comp Height: 1.33, -15cc Dish Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-9.16, 66cc-8.98, 72cc-8.47
Choose Options
2813-3903 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.903 inch bore COMP HEIGHT: 1.33 2813-3903 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.903 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
347 Chevy LS, FX, Comp Height: 1.33, -15cc Dish Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-9.18, 66cc-9, 72cc-8.49
Choose Options
2813-3913 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.913 inch bore COMP HEIGHT: 1.33 2813-3913 4.8 - 5.3 - LS1 - LS6 Chevy LS FX Series -15cc Dish Top LS1,LS2,LS3 and LS7 Forged Piston Set 3.913 inch bore COMP HEIGHT: 1.33
from $669.95
from $669.95
348 Chevy LS, FX, Comp Height: 1.33, -15cc Dish Top, PIN: .943", Full-Floating or Press Fit, Ring Groove: 1.2/1.2/3MM, Stroke: 3.622", ROD: 6.098, Approx Comp Ratio: 64cc-9.21, 66cc-9.03, 72cc-8.51
Choose Options
