AMX Javelin

AMC

Cylinder Bore Size Show all Cylinder Bore Size
With Rings \ Without Rings Show all With Rings \ Without Rings
Crankshaft Stroke Show all Crankshaft Stroke
Connecting Rod Length Show all Connecting Rod Length
Piston Pin Diameter Show all Piston Pin Diameter
Compression Height Show all Compression Height
Cylinder Head Type Show all Cylinder Head Type
Piston Series Show all Piston Series
TDC Assembly Height Show all TDC Assembly Height
Piston Top Aprox. Comp. Ratio Show all Piston Top Aprox. Comp. Ratio
1-6600-4080 360 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.080 bore 1-6600-4080 360 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.080 bore
$669.95
$669.95
360 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.590" -3cc AMC Flat Top Pin: 0.931 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.440" Rod: 5.875" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-12.98, 54cc-12.25, 58cc-11.60 NOTE: Pistons include a .001 oversize pin ( .931 ) Connecting rod pin bore adjustment is required.
1-6600-4110 360 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.110 bore 1-6600-4110 360 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.110 bore
$669.95
$669.95
360 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.590" -3cc AMC Flat Top Pin: 0.931 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.440" Rod: 5.875" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-13.12, 54cc-12.38, 58cc-11.73 NOTE: Pistons include a .001 oversize pin ( .931 ) Connecting rod pin bore adjustment is required.
1-6600-4120 360 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.120 bore 1-6600-4120 360 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.120 bore
$669.95
$669.95
360 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.590" -3cc AMC Flat Top Pin: 0.931 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.440" Rod: 5.875" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-13.18, 54cc-12.44, 58cc-11.78 NOTE: Pistons include a .001 oversize pin ( .931 ) Connecting rod pin bore adjustment is required.
1-6600-4140 360 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.140 bore 1-6600-4140 360 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.140 bore
$669.95
$669.95
360 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.590" -3cc AMC Flat Top Pin: 0.931 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.440" Rod: 5.875" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-13.26, 54cc-12.51, 58cc-11.86 NOTE: Pistons include a .001 oversize pin ( .931 ) Connecting rod pin bore adjustment is required.
1-6605-4080 360 AMC V8 1-FX Series -21cc AMC Dish Top Forged Piston Set. 4.080 bore 1-6605-4080 360 AMC V8 1-FX Series -21cc AMC Dish Top Forged Piston Set. 4.080 bore
$669.95
$669.95
360 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.590" -21cc AMC Dish Top Pin: 0.931 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.440" Rod: 5.875" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-10.27, 54cc-9.82, 58cc-9.42 NOTE: Pistons include a .001 oversize pin ( .931 ) Connecting rod pin bore adjustment is required.
1-6605-4110 360 AMC V8 1-FX Series -21cc AMC Dish Top Forged Piston Set. 4.110 bore 1-6605-4110 360 AMC V8 1-FX Series -21cc AMC Dish Top Forged Piston Set. 4.110 bore
$669.95
$669.95
360 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.590" -21cc AMC Dish Top Pin: 0.931 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.440" Rod: 5.875" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-10.38, 54cc-9.93, 58cc-9.53 NOTE: Pistons include a .001 oversize pin ( .931 ) Connecting rod pin bore adjustment is required.
1-6605-4120 360 AMC V8 1-FX Series -21cc AMC Dish Top Forged Piston Set. 4.120 bore 1-6605-4120 360 AMC V8 1-FX Series -21cc AMC Dish Top Forged Piston Set. 4.120 bore
$669.95
$669.95
360 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.590" -21cc AMC Dish Top Pin: 0.931 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.440" Rod: 5.875" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-10.43, 54cc-9.98, 58cc-9.57 NOTE: Pistons include a .001 oversize pin ( .931 ) Connecting rod pin bore adjustment is required.
1-6605-4140 360 AMC V8 1-FX Series -21cc AMC Dish Top Forged Piston Set. 4.140 bore 1-6605-4140 360 AMC V8 1-FX Series -21cc AMC Dish Top Forged Piston Set. 4.140 bore
$669.95
$669.95
360 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.590" -21cc AMC Dish Top Pin: 0.931 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.440" Rod: 5.875" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-10.50, 54cc-10.04, 58cc-9.63 NOTE: Pistons include a .001 oversize pin ( .931 ) Connecting rod pin bore adjustment is required.
1-6610-4165 390 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.165 bore 1-6610-4165 390 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.165 bore
$669.95
$669.95
390 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.550" -3cc AMC Flat Top Pin: 1 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.574" Rod: 5.858" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-13.90, 54cc-13.12, 58cc-12.42
1-6610-4185 390 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.185 bore 1-6610-4185 390 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.185 bore
$669.95
$669.95
390 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.550" -3cc AMC Flat Top Pin: 1 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.574" Rod: 5.858" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-13.98, 54cc-13.19, 58cc-12.50
1-6610-4195 390 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.195 bore 1-6610-4195 390 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.195 bore
$669.95
$669.95
390 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.550" -3cc AMC Flat Top Pin: 1 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.574" Rod: 5.858" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-14.04, 54cc-13.25, 58cc-12.55
1-6615-4165 390 AMC V8 1-FX Series -25cc AMC Dish Top Forged Piston Set. 4.165 bore 1-6615-4165 390 AMC V8 1-FX Series -25cc AMC Dish Top Forged Piston Set. 4.165 bore
$669.95
$669.95
390 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.550" -25cc AMC Dish Top Pin: 1 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.574" Rod: 5.858" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-10.52, 54cc-10.09, 58cc-9.69
1-6615-4185 390 AMC V8 1-FX Series -25cc AMC Dish Top Forged Piston Set. 4.185 bore 1-6615-4185 390 AMC V8 1-FX Series -25cc AMC Dish Top Forged Piston Set. 4.185 bore
$669.95
$669.95
390 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.550" -25cc AMC Dish Top Pin: 1 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.574" Rod: 5.858" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-10.58, 54cc-10.15, 58cc-9.75
1-6615-4195 390 AMC V8 1-FX Series -25cc AMC Dish Top Forged Piston Set. 4.195 bore 1-6615-4195 390 AMC V8 1-FX Series -25cc AMC Dish Top Forged Piston Set. 4.195 bore
$669.95
$669.95
390 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.550" -25cc AMC Dish Top Pin: 1 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.574" Rod: 5.858" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-10.63, 54cc-10.19, 58cc-9.79
1-6620-4165 401 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.165 bore 1-6620-4165 401 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.165 bore
$669.95
$669.95
401 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.500" -3cc AMC Flat Top Pin: 1 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.680" Rod: 5.858" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-14.26, 54cc-13.46, 58cc-12.75
1-6620-4185 401 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.185 bore 1-6620-4185 401 AMC V8 1-FX Series -3cc AMC Flat Top Forged Piston Set. 4.185 bore
$669.95
$669.95
401 AMC V8 1-FX Series 4032 Alloy Comp Hgt: 1.500" -3cc AMC Flat Top Pin: 1 Ring Grooves: 1/16-1/16-3/16" Stroke: 3.680" Rod: 5.858" Boost and NOS Ready! (Moderate to High Levels) Aprox Comp Ratio: 50cc-14.38, 54cc-13.57, 58cc-12.85
